Deye SE-F16 MAX 16.38kWh LV energy storage IP65

Šifra: SE-F16 MAX

Nominal Energy: 16 kWh
Operating Voltage: 44.8 V ~ 57.6 V
Capacity: 314 Ah


Certifikati (klikni za pregled i preuzimanje):

Verification of Compliance (EN IEC 61000-6-1:2019 , EN IEC 61000-6-3:2021)

Verification of Compliance ( EN 300 328 V2.2.2 , EN 301 489-1 V2.2.3 , EN 61000-3-12:2011 +A1:2024, EN IEC 61000-3-11: 2019, EN 301 489-17 V3.3.1 , EN IEC 62311:2020)


  • NEPT F_SE-F16 Max (-H) Series
  • Battery Chemistry LiFePO4
  • Nominal Voltage (V) 51.2
  • Operating Voltage(V) 44.8 - 57.6
  • Nominal Energy (kWh) 16
  • Max. Output Power (kW) 11.8
  • Recommend Depth of Discharge 90% DoD
  • Dimension (W/H/D)(mm)
  • (Without hanging board and terminals) 464*914*244.5
  • Weight Approx. (kg) 118
  • Display LCD(SOC, Alarm)
  • Ingress Protection Rating/Enclosure Rating IP65/NEMA 3R
  • Storage Temperature 0℃~35℃
  • Relative Humidity 95% (non-condensing)
  • Altitude (m/ft) ≤3000/9843
  • Cycle Life ≥8000(25℃±2℃ ,70%EOL)
  • Isolation Protection Built-in Circuit Breaker
  • Installation Wall-Mounted, Floor-Mounted
  • Communication CAN2.0, RS485, Bluetooth
  • Certification UN38.3, CE, CB, UL9540A
  • Warranty Period 10 years

Min. količina za narudžbu: 1
